NOX-431

4" Onyx, Round LED Reflector

Onyx Retrofit Series is suitable for use with most 4″ recessed housings. Die-cast aluminum construction provides clean sharp edges. Deep regressed optics and round aperture delivers even and glare-free illumination. Available in multiple color temperatures and 90+ CRI.

Features:

  • 650 or 900 lumens
  • 2700K, 3500K, 4000K or 5000K @ 90+ CRI
  • Integral dimmable driver
  • Recessed mount into 4″ housing. Includes medium base socket adaptor for easy retrofitting in 4″ recessed housings
  • Quick connector is compatible with Nora NHIC -4LMRAT and NHRIC-4LMRAT dedicated LED housings. Required by some codes in recessed can applications or to meet energy rebate program requirements

Accessories:
NOX-4EYELID: 4″ Round Eyelid for Onyx
NOX-4OR-W: 4″ Round Oversize Ring for Onyx

Downloads

Downloads

• Specification Sheet

• IES File

• Instruction Sheet

Additional information

Light Source

LED

Lumen Output

0-900lm

Aperture Size

4"

Application

Downlight

Construction Type

Retrofit, Shallow

Options

ENERGY STAR certified, Wet Location
